MACHINE FEATURES:

Our machine has simple innovative design and ultimate energy saving. It is engineered for efficiency and maximum production speed.

• Blowing Toggle System for Easy and Lesser Mould Changing Time (Max.10min).
• Incremental Heater Settings by 1% to 199% for Accurate Pre-form Heat Setting.
• Air & Water Lines are Push & Pull System for Easy Maintenance.
• Long Life PU Seal Cylinders and Higher Accuracy Valves used for Low Pressure Control System.
• IP67 Grade Sensors used for Higher Accuracy & Long Life.
• Advanced PLC Based System with 7” Multi colour HMI Unit used for Easy Man Machine Interfacing and Higher Machine Performance.
• Multiple Products Like Mineral Water Bottles, Carbonated Soft Drinks Bottles, Hot Fill Juice Bottles at Low Investment.
• Machine Can Store 20 Mould Recipe Parameters so it helps to reduce Mould Changing Time.
• High Productivity with Low Power Consumption.
• Easy operation & Easy maintenance.
• Production Display with Man Machine Interfacing Facility. The multi colour touch screen display is used to graphically view all the parameters.
• Compact Structure and low maintenance cost.

TECHNICAL SPECIFICATION:

Machine Specification

• Machine Category: Semi Automatic
• Machine Model: AVY-61 Semi Automatic
• No of Cavities: 2 Cavity

Production Capacity (Bottles/Hour) (Depending on Moulds and pre-form Quality)

• 1100 BPH for 300ml
• 1000 BPH for 500ml
• 900 BPH for 1000ml

Blowing Capacity

• 300ml – 1.000ml

Bottle Outlet

• Auto Drop

Size of the Mould (Width x Thickness)

• 120mm x 125mm (Each)

Electrical System

• Pre-heating System: Near Infrared
• No of Heaters: 8 Nos
• Heater Capacity: 2000 Watts
• Machine Connected Power: 5KW, 3 Phase
• Machine with accessories Connected Power: 23KW, 3 Phase
• Total Power Consumption (Include accessories): 16KWH (Units)

Air System

• Blowing Pressure: 20Bar
• Working Pressure: 6Bar
• Air Consumption: 38CFM

Required Accessories

• Compressor Capacity (High Pressure): 20HP/25Bar/54CFM

What is a 2 Cavity Semi-Automatic Stretch Blow Molding Machine?

A 2 cavity semi-automatic stretch blow molding machine produces two PET bottles per cycle using preforms. The process involves:

1. Heating PET preforms in an infrared oven
2. Stretching the preform with a stretch rod
3. Blowing high-pressure air to shape the bottle inside a mold

Being semi-automatic, it requires minimal manual intervention for loading and unloading, while the molding process itself remains precise and controlled.

Key Features

• Two-cavity mold design for higher productivity
• Robust body structure for long-term industrial use
• Uniform heating system for consistent bottle thickness
• Low power consumption compared to fully automatic machines
• Easy mold change system for different bottle sizes
• User-friendly operation & maintenance

Technical Specifications (Typical Range)

(Specifications may vary as per customer requirements.)

Applications

• Packaged Drinking Water Bottles
• Edible Oil & Cooking Oil Bottles
• Soft Drink & Juice Bottles
• Pharmaceutical & Cosmetic Containers
• Household Chemical Bottles

Advantages for Indian Manufacturers

• Affordable investment for new entrepreneurs
• Lower maintenance cost
• Skilled-labor friendly design
• Suitable for Indian power conditions
• Strong after-sales support from Heerawati Foods Packaging Machines

Why Choose Heerawati Foods Packaging Machines India Pvt. Ltd.?

• Proven expertise in food & beverage packaging machinery
• Custom-built machines as per production needs
• Focus on quality, durability, and performance
• Reliable installation, training, and service support across India

Conclusion

The 2 Cavity Semi-Automatic Stretch Blow Molding Machine from Heerawati Foods Packaging Machines India Pvt. Ltd. is a smart and economical solution for PET bottle manufacturing. With dependable performance, flexible production capacity, and low operating costs, it is perfectly suited for businesses looking to establish or expand their bottle production line.
