In today’s fast-growing beverage, edible oil, pharmaceutical, and FMCG industries, PET bottles have become the preferred packaging solution due to their strength, clarity, and recyclability. To meet high production demands with consistent quality, Full Automatic PET Blowing Machines play a crucial role.
Heerawati Foods Packaging Machines India Pvt Ltd offers advanced, reliable, and cost-effective PET blowing solutions designed for Indian manufacturing conditions.
What Is a Full Automatic PET Blowing Machine?
A Full Automatic PET Blowing Machine converts PET preforms into finished bottles using a fully automated process. From preform feeding to heating, stretching, blowing, and bottle discharge—everything is controlled electronically, ensuring high speed, accuracy, and minimal human intervention.
Key Features of Heerawati’s Full Automatic PET Blowing Machine
Fully Automatic Operation – Reduces labor cost and human error
High Production Capacity – Ideal for medium to large-scale plants
Energy Efficient Heating System – Optimized IR heaters for uniform heating
PLC & Touch Screen Control – Easy operation and real-time monitoring
Consistent Bottle Quality – Uniform thickness, clarity, and strength
Low Maintenance Design – Robust components with long service life
Technical Highlights
Bottle Capacity: 50 ml to 2 L / 5 L (model dependent)
Production Output: Up to 2,000–8,000 bottles/hour
Automation Type: Fully Automatic
Control System: PLC-based with HMI
Air Pressure: High-pressure compressed air system
Applications: Water, edible oil, soft drinks, juices, pharma liquids
Applications Across Industries
Packaged drinking water plants
Edible oil and lubricant manufacturers
Soft drink and beverage companies
Pharmaceutical and cosmetic packaging units
Chemical and household product manufacturers
Advantages of Choosing Heerawati Foods Packaging Machines
Made in India, Made for India – Designed for local power and climate conditions
Customizable Solutions – Machines tailored to bottle size and output needs
After-Sales Support – Installation, training, and service support across India
Competitive Pricing – High ROI with long-term reliability
Conclusion
A Full Automatic PET Blowing Machine from Heerawati Foods Packaging Machines India Pvt Ltd is an ideal investment for businesses aiming to scale production, improve packaging quality, and reduce operational costs. With robust construction, advanced automation, and dependable service support, these machines empower manufacturers to stay competitive in today’s demanding market.
Technical Specifications of Fully Automatic Machine Astra-260 SERIES CSD & Water
1) Volume & Neck Size Suitable
300 ML to 1500 ML suitable for neck diameter of 28 MM at 30 Bar Air Pressure
2) Production Range
| SR NO | PRODUCT VOLUME | Output (In BPM) | Required Air Pressure (Bar) | Required HP Air (CFM) | Required LP Air (CFM) | Required Air Pressure (bar) |
|---|---|---|---|---|---|---|
| 1 | 200 ML | 40 BPM | 30 | 30 | 40 | 10 |
| 2 | 500 ML | 40 BPM | 30 | 40 | 40 | 10 |
| 3 | 1000 ML | 35 BPM | 30 | 60 | 40 | 10 |
| 4 | 2000 ML | 30 BPM | 30 | 50 | 40 | 10 |
3) Infrared Pre-heating System
1900 MM Two Module 7 Zone Infrared Heating Length with conveyorised preheating system to maintain uniform pre-heating.
Incremental heater settings by 1% to 99%.
4) Direct Preform Transfer Mechanism
Direct preform transfer mechanism from infrared pre-heating unit to blowing unit for reduced manpower & achieve maximum production output.
5) Automatic Bottle Ejection
Automatic bottle ejection with gripper mechanism for reduced manpower.
6) High Pressure Blowing Valve
Highly efficient high pressure diaphragm type Parker make blowing valve with No Preform No Blow System for reduced air consumption.
7) Mould Clamping Unit
40 Ton Toggle Mechanism for mould clamping unit.
8) PLC & HMI Display
Telemecanique Schneider Modicon M200 Micro Series PLC
HMI Display: Telemecanique Schneider TFT 7” Colour Touch Screen, 320 x 240 Pixels, 16 Mb Flash EPROM, Alarm log, alphanumeric entry, 20 level passwords, serial printing, 32 (group) x 64 = 2048 mould memory
9) Preform Pre-heating Conveyor Electrical Type controlled with AC Variable Frequency Drive
Bonfiglioli Gear Motor with AC Variable Drive.
10) Leakproof Festo Plumbing System
Pneumatic air & water cooling Festo make leakproof push type plumbing system.
11) Extra Set of Tools
Set of tools & operation manual for Hydro-Pneumatic & Telemecanique Schneider PLC & HMI.
Fully Automatic Machine Astra-260 SERIES CSD & Water (Included / Package Items Mentioned)
Preform Storage Hopper & Automatic Feeder for reduced manpower
Bottle Carrying Conveyor With
ONE YEAR RECOMMENDED SPARES & EXPORT SEA WORTHY PACKING CHARGES
Moulds Mentioned
300 ML Mould DIA 28 mm with water cooling system & diamond polish
500 ML Mould DIA 28 mm with water cooling system & diamond polish
1000 ML Mould DIA 28 mm with water cooling system & diamond polish
1500 ML Mould DIA 28 mm with water cooling system & diamond polish
Compressors / Dryer / Chiller Mentioned
40 HP Duplex (20 x 2) HP High Pressure Air Cooled Compressor
with moisture separator
Working Pressure 35 Bar
FAD = 74 CFM
80 CFM / 40 Bar High Pressure Refrigerator Air Dryer
20 HP Low Pressure Air Cooled Compressor
with moisture separator
Working Pressure 10 Bar
FAD = 60 CFM
65 CFM / 10 Bar Low Pressure Refrigerator Air Dryer
3 TR Water Chiller Air Cooled
